Main |
||
Main Input Voltage |
230 V |
|
Other Input Voltage |
220 V |
|
Main Output Voltage |
230 V |
|
Other Output Voltage |
220 V |
|
rated power in W |
10000 W |
|
Rated power in VA |
10000 VA |
|
output connection type |
6 IEC 60320 C13 |
|
Output connector type |
Hardwire 3-wire (H N + E) 1 |
|
Battery type |
Lead-acid battery |
|
Provided equipment |
CD with software |
|
|
||
Batteries & Runtime |
||
Run Time |
||
Efficiency |
||
Number of battery filled slots |
0 |
|
Battery recharge time |
1.5 h |
|
Number of battery replacement quantity |
2 |
|
Battery voltage |
+/- 192 V (split battery referenced to neutral) |
|
Battery charger power |
876 W rated |
|
Battery power in VAH |
1805 VAh runtime |
|
Battery life |
3…5 year(s) |
|
Replacement battery |
||
Battery option |
SRT192BP2 1 3610 VAh |
|
Extended runtime |
1 |
|
|
||
General |
||
product web sub-family |
High density |
|
Number of power module free slots |
0 |
|
Number of power module filled slots |
0 |
|
Redundant |
No |
|
|
||
Physical |
||
Colour |
Black |
|
Height |
43.2 cm |
|
Width |
26.3 cm |
|
Depth |
71.5 cm |
|
Product weight |
111.82 kg |
|
Mounting location |
Front |
|
Mounting preference |
No preference |
|
Mounting mode |
Rack-mounted with kit |
|
Two posts mountable |
0 |
|
USB compatible |
Yes |
|
|
||
Input |
||
Network frequency |
40...70 Hz auto-sensing |
|
Number of input connectors |
1 hard wire 3-wire (1P + N + E) |
|
Input voltage limits |
100...275 V adjustable (half load) |
|
|
||
Output |
||
Maximum configurable power in W |
10000 W |
|
Harmonic distortion |
Less than 2 % |
|
Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
|
Crest factor |
3:1 |
|
UPS type |
Double conversion online |
|
Wave type |
Sine wave |
|
bypass type |
Internal bypass (automatic and manual) |
|
Maximum configurable power in VA |
10000 VA |
|
|
||
Conformance |
||
Product certifications |
CE |
|
Marking |
CE Mark |
|
Standards |
EN/IEC 62040-1:2019/A11:2021 |
|
Conformance |
||
Product certifications |
CE |
|
Marking |
CE Mark |
|
Standards |
EN/IEC 62040-1:2019/A11:2021 |
|
|
||
Environmental |
||
Ambient air temperature for operation |
0…40 °C |
|
Relative humidity |
0…95 % |
|
Operating altitude |
0...10000 ft |
|
Ambient air temperature for storage |
-15…45 °C |
|
Storage Relative Humidity |
0…95 % non-condensing |
|
Storage altitude |
0.00…15240.00 m |
|
Acoustic level |
55 dBA |
|
Heat dissipation |
1947 Btu/h |
|
IP degree of protection |
IP20 |
|
|
||
Communications & Management |
||
Free slots |
1 |
|
Preinstalled device |
Network management card 3 with environmental monitoring |
|
Alarm |
Audible and visible alarms : prioritized by severity |
|
Emergency power off |
Yes |
|
|
||
Surge Protection and Filtering |
||
Surge energy rate |
480 J |
|
|
||
Packing Units |
||
Unit Type of Package 1 |
PCE |
|
Number of Units in Package 1 |
1 |
|
Package 1 Height |
46.1 cm |
|
Package 1 Width |
60 cm |
|
Package 1 Length |
100 cm |
|
Package 1 Weight |
126.554 kg |
|
|
||
Contractual warranty |
||
Warranty |
3 years for repair or replacement (excluding battery) and 2 years for battery |
